| 功率 | 41-123 |
|---|---|
| 额定电压 | 220-380 |
| 速度响应频率 | 40-60 |
| 品牌 | 晟昌 |
| 型号 | SPMA-138 |
产品说明：
| Motor Type | Rated Power Kw | Rated Speed RPM | Rated Torque Nm | Rated Frequency Hz | Rated Current A | Max Speed RPM | Peak Torque Nm | Ke (E.M.F) vRMS /1000rpm | Kt Nm /Arms | Inertia Kg-cm2 | Resistance Ohm | Inductance mH | Weight Kg |
| SPM-137-10 | 37.5 | 1000 | 355 | 66.7 | 71.0 | 4000 | 1062 | 300 | 5 | 570 | 0.1 | 7.2 | 207.0 |
| SPM-137-15 | 56.3 | 1500 | 355 | 100.0 | 106.5 | 4000 | 1062 | 200 | 3.6 | 570 | 0.1 | 3.2 | |
| SPM-137-20 | 75 | 2000 | 355 | 133.3 | 142.0 | 4000 | 1062 | 150 | 2.5 | 570 | 0.0 | 1.8 | |
| SPM-137-30 | 112.5 | 3000 | 355 | 200.0 | 213.0 | 4000 | 1062 | 100 | 1.7 | 570 | 0.0 | 0.8 | |
| SPM-138-10 | 41 | 1000 | 388 | 66.7 | 77.5 | 4000 | 1169 | 300 | 5 | 630 | 0.1 | 6.6 | 228.0 |
| SPM-138-15 | 61.5 | 1500 | 388 | 100.0 | 116.3 | 4000 | 1169 | 200 | 3.6 | 630 | 0.0 | 2.9 | |
| SPM-138-20 | 82 | 2000 | 388 | 133.3 | 155.0 | 4000 | 1169 | 150 | 2.5 | 630 | 0.0 | 1.7 | |
| SPM-138-30 | 123 | 3000 | 388 | 200.0 | 232.5 | 4000 | 1169 | 100 | 1.7 | 630 | 0.0 | 0.7 |
