| 应用范围 | 控制 |
|---|---|
| 产品系列 | T73 |
| 触点形式 | 常开型 |
| 额定电流 | 12V |
| 额定电压 | 10A |
| 防护特征 | 密封式 |
| 线圈功率 | 0.36W |
| 品牌 | HONHCIN |
| 型号 | HRA |
广泛运用于家电控制器,汽车电子等电器设备
■ConTACT DATA触点参数
Contact Form触点形式 | 1A/1C |
|
Contact Material触点材料 | Silver Alloy |
|
Contact Ratings触点负载 | 1A:10A 240VAC, 15A 12VDC(TUV) 12A 120VAC/24VDC | 1C: 7A 240VAC/10A 120VAC/24VDC 5A 240VAC(TUV) |
Max Switching Voltage**大转换电压 | 250VAC/30VDC |
|
Max Switching Current**大转换电流 | 15A |
|
Max Switching Power**大转换功率 | 2770VA/240W |
|
Contact Resistance接触电阻 | 100mΩMax | at 6VDC 1A |
Life Expectancy Electrical电气寿命 | 100,000 | Operations(at30Operations/minute) |
Machanical机械寿命 | 10,000,000 | Operations |
■GENERAL DATA一般参数
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
|
|
| |
|
| |
|
| |
|
| |
Safety Standard安全标准 | TUV CQC UL | |
■COIL DATA线圈参数
NominalVoltage 额定电压 (VDC) | Coil Resistance at20℃?10%(Ω) 线圈阻值 | Max Operate Voltage **大吸合电压 VDC | Min ReleaseVoltage **小释放电压 VDC | Max ApplicableVoltage **大过载电压 VDC | |
0.36W | 0.45W | ||||
3 | 25Ω |
| 2.25 | 0.3 | 3.9 |
5 | 70Ω |
| 3.75 | 0.5 | 6.5 |
6 | 100Ω |
| 4.5 | 0.6 | 7.8 |
9 | 225Ω |
| 6.75 | 0.9 | 11.7 |
12 | 400Ω |
| 9 | 1.2 | 15.6 |
18 | 900Ω |
| 13.5 | 1.8 | 23.4 |
24 | 1600Ω |
| 18 | 2.4 | 31.2 |
48 | 6400Ω?15% | 5100Ω?15% | 36 | 4.8 | 62.4 |
