青岛精展机电技术有限公司

主要规格          单位        XYL04-0.5             XYL04-1           XYL04-2            XYL04-3

公称力              KN               5                         10                  20                      20

滑块行程           MM             26                        40                  40                      40

滑块行程次数      SPM         260                       260                240                   240

**大封闭高度        MM          115                      150                150                  150

立柱间距离           MM          102                      106                120                  120

模柄孔直径           MM           16                        20                      25                 25

工作台尺寸           MM        252*252           270*270            290*300         310*310

电动机功率           W            250                  370                     450                   550

外形尺寸        MM         460*305*450   470*320*540              630*460*700     630*460*700

净重               KG         60                  80                 127                140
