品牌:荣世电器
型号:28BYGH
起订:1
发货:10天内
发送询价
| 品牌 | 荣世电器 |
|---|---|
| 型号 | 28BYGH |
Electrical Specifications(技术数据):
| 型号SeriesModel | 步距角StepAngle(°) | 机身长MotorLength(mm) | 电流RatedCurrent(A) | 电阻PhaseResistance(Ω) | 电感PhaseInductance(mH) | 静力矩HoldingTorque(N.cm Min) | 定位力矩DetentTorque(N.cm Max) | 转动惯量RotorInertia(g.cm2) | 引线数LeadWire(No.) | 重量MotorWeight(g) |
| 11HY2406 | 1.8 | 28 | 0.6 | 4.2 | 2.2 | 4.5 | 0.3 | 6 | 4 | 105 |
| 11HY24035 | 1.8 | 28 | 0.35 | 12 | 5.8 | 4.5 | 0.3 | 6 | 4 | 105 |
| 11HY3406 | 1.8 | 33 | 0.6 | 5.5 | 3.2 | 6.0 | 0.4 | 8 | 4 | 110 |
| 11HY34035 | 1.8 | 33 | 0.35 | 15 | 9.2 | 6.0 | 0.4 | 8 | 4 | 110 |
| 11HY4406 | 1.8 | 41 | 0.6 | 7.0 | 6.0 | 6.0 | 0.5 | 11 | 4 | 140 |
| 11HY44035 | 1.8 | 41 | 0.35 | 20 | 15 | 6.0 | 0.5 | 11 | 4 | 140 |
| 11HY5406 | 1.8 | 50 | 0.6 | 9.0 | 7.2 | 10 | 0.8 | 13 | 4 | 180 |
| 11HY54035 | 1.8 | 50 | 0.35 | 24 | 18.5 | 10 | 0.8 | 13 | 4 | 180 |
