| 表面处理 | 不经处理 |
|---|---|
| 产品等级 | A级 |
| 类别 | 平头 |
| 应用范围 | 机械工业用紧固件 |
| 作用方式 | 手拧 |
| 标准编号 | GB81885 |
| 头型 | 扁圆头 |
| 槽型 | 一字 |
| 品牌 | 零件买卖网 |
| 型号 | 平头一字螺丝 |
| 加工定制 | 否 |
| 材料等级 | 塑料 |
| 一、产品简图（Product sketch） | ||||||||
| ||||||||
| 型号 | 产品编号 | 螺纹规格 | L | ФD | A | B | H | |
| M2*6C | 105020450411 | M2*0.40 | 6 | 3.8 | 0.7 | 1 | 1.35 | |
| M3*3C | 105020450371 | M3*0.5 | 3 | 5.5 | 1 | 1.3 | 2 | |
| M3*4C | 105020450391 | 4 | 5.5 | 1 | 1.3 | 2 | ||
| M3*5C | 105020450011 | 5 | 5.5 | 1 | 1.3 | 2 | ||
| M3*6C | 105020450021 | 6 | 5.5 | 1 | 1.3 | 2 | ||
| M3*8C | 105020450031 | 8 | 5.5 | 1 | 1.3 | 2 | ||
| M3*10C | 105020450041 | 10 | 5.5 | 1 | 1.3 | 2 | ||
| M3*20C | 105020450081 | 20 | 5.5 | 1 | 1.3 | 2 | ||
| M4*5C | 105020450181 | M4*0.7 | 5 | 7 | 1.2 | 1.6 | 2.6 | |
| M4*6C | 105020450191 | 6 | 7 | 1.2 | 1.6 | 2.6 | ||
| M4*8 | 105020450441 | 8 | 7 | 1 | 1.8 | 2.8 | ||
| M4*8C | 105020450201 | 8 | 7 | 1.2 | 1.6 | 2.6 | ||
| M4*10 | 105020450451 | 10 | 7 | 1 | 1.8 | 2.8 | ||
| M4*10C | 105020450211 | 10 | 7 | 1.2 | 1.6 | 2.6 | ||
| M4*12C | 105020450221 | 12 | 7 | 1.2 | 1.6 | 2.6 | ||
| M4*16 | 105020450231 | 16 | 7 | 1 | 1.8 | 2.8 | ||
| M4*16C | 105020450351 | 16 | 7 | 1.2 | 1.6 | 2.6 | ||
| M4*25C | 105020450261 | 25 | 7 | 1.2 | 1.6 | 2.6 | ||
| M4*30C | 105020450291 | 30 | 7 | 1.2 | 1.6 | 2.6 | ||
| M4*35C | 105020450321 | 35 | 7 | 1.2 | 1.6 | 2.6 | ||
| M4*40C | 105020450341 | 40 | 7 | 1.2 | 1.6 | 2.6 | ||
| M5*25C | 105020450401 | M5*0.8 | 35 | 8.5 | 1.5 | 2 | 3.3 | |
| M6*40C | 105020450381 | M6*1.0 | 40 | 10 | 1.9 | 2.3 | 3.9 | |
规格型号不一样，产品单价不一样！~
三、产品用途(Application)
塑料螺丝目前广泛应用于电子产品，家用电器、通信天线、造船、航天航空、机械制造、LED灯具，展示架等行业，取代传统的五金螺丝；特点是重量轻、体积小、绝缘、美观、环保、不生锈、安装方便、快捷等优点。颜色有黑色，白色，自然色，还可按照客户所需颜色调色，规格齐全。
Plastic screws are currently widely applied in electronic products, household appliance,communication antennas, ship construction, aerospace, machine manufacture, LED lamps, anddisplay rack industries, etc.; they replace metal screws in function.Feature: light in weight, small in size, good in insulation, artistic, environmentalprotected, and stainless, it is easily, conveniently, and fast to install and use; it iscomplete in specifications and there are diverse color as black, white, and natural insupply, moreover, the color can be customized.
四、产品性能(Function)
塑料螺丝又叫塑胶螺丝、尼龙螺丝、绝缘螺丝，头型和尺寸一般参照五金螺丝的标准制造，一般由PA66、PC绝缘塑料制作。作用是对两个分离的物件起到连接和紧固作用。主要利用塑料材料本身的绝缘、密度小、无电磁干扰的性能，从而实现其绝缘连接和紧固功能。安装时只要用电动螺丝批即可安装，省时、方便、快捷。
Plastic screws are also called as nylon screws, insulating screws, the dimensions and headtypes of plastic screws refer to those of metal screws; generally, plastic screws are madefrom insulating plastic material as PA66 and PC; they function to unit and fasten twoseparate parts. It realizes insulating connection and fastening of separated parts byutilizing the insulation, low density, and no electromagnetic interference nature of plasticmaterial. Plastic screws are easily, conveniently, and fast to be mounted by electricscrewdrivers.
=================================================
