品牌:欣睿激光
空载电压:380V
电流调节范围:50A
起订:1台
供应:10000台
| 空载电压 | 380V |
|---|---|
| 电流调节范围 | 50A |
| 额定焊接电流 | 50A |
| 使用焊丝直径 | 0.3mm |
| 种类 | 自动焊接设备 |
| 品牌 | 欣睿激光 |
| 型号 | XR-JXS-FW600 |
| 加工定制 | 是 |
特点：feature
通过实时能量闭环反馈功能可获得稳定理想的波形，确保路焊接的稳定性；
The stable and ideal waveform can be obtained by the real time energy feedback function, ensure the stability of road welding;
可快速切换焊接条件，实现高速高品质焊接； Fast switching condition,high speed and high quality welding;
与振镜组合使用可实现一定区域的高速点焊缝焊；
The use of high speed can achieve a certain region of the welding seam and the galvanometer combination;
激光输出支持时间分光、能量分光、瞬时分光，最多4路分光；
Laser output support time、 Energy splitting、Instantaneous splitting、Up to 4 points of light；
具有能量缓升缓降功能，在缝焊时保证开始与结束的重叠部分整齐美观；
With energy slow up slow down function，in the seam ensure overlapping part of the beginning and end of the neat appearance；
通过内置的能量监测仪可以监测激光能量与平均输出功率的异常.
The laser energy and the average output power can be monitored by the built-in energy monitor.
技术参数technical parameter
|
| XR-FW50 | XR-FW150 | XR-FW300 | XR-FW500 | XR-FW600 |
| 最大激光功率 Max. Laser mean power | 50W | 150W | 300W | 500W | 600W |
| 激光波长 Laser wavelength | 1064nm | ||||
| 单脉冲最大激光能量 Single pulse Max. power | 50J | 65 | 75 | 100J | 100J |
| 脉冲宽度 Pulse width | 0.5ms-15ms | ||||
| 脉冲频率 Pulse frequency | 1-100HZ | ||||
| 光纤输出数量 Fiber output quantity | 最多4路 Up to four routes | ||||
| 反馈类型 Feedback type | 能量反馈 Current minus feedback | ||||
| 分光方式 Share way | 能量分光/时间分光/瞬时分光 Energy share/time share/instant share | ||||
| 整机耗电功率 Power consumption | 4KW | 6KW | 12KW | 15KW | 16KW |
| 电力需求 Power supply | 单相；220V/50HZ single phase | 三相；380V/50HZ three phase | |||
| 冷却系统 Cooling system | 水冷(内置水冷可选) water cooling（internal water/ air optional） | ||||
| 光纤型号 Fiber model | 三菱SI/GI光纤 Mitsubishi SI/GI fiber | ||||
