南京腾阳非标订做油脂融化加热箱

概述：I.overview:

本公司开发高性能的腾阳牌大型烘箱和加热室，可以对温度**控制。温度偏差小，自动化程度高，干燥和加热时受热均匀，并伴有热风均匀吹拂被干燥的特殊装置。性能可靠。本公司已成功为浙江和天津南京某外资油品企业设计、安装了60-100㎡的大型烘房和150㎡的加热室。已无故障使用了六年。高性能的腾阳牌大型烘房和加热室，广泛应用于润滑油品和添加剂和**陶瓷行业的模具和产品的干燥，而且能源得到**好的利用，是良好的节能设备。南京腾阳干燥设备厂可以提供从设计、制造、安装和售后服务的全方位**服务。

本公司开发高性能的腾阳牌大型烘箱和加热室，可以对温度**控制。温度偏差小，自动化程度高，干燥和加热时受热均匀，并伴有热风均匀吹拂被干燥的特殊装置。性能可靠。本公司已成功为浙江和天津 南京某外资油品企业设计、安装了60-100㎡的大型烘房和150㎡的加热室。已无故障使用了六年。高性能的腾阳牌大型烘房和加热室，广泛应用于润滑油品和添加剂和**陶瓷行业的模具和产品的干燥，而且能源得到**好的利用，是良好的节能设备。南京腾阳干燥设备厂可以提供从设计、制造、安装和售后服务的全方位**服务。

I.overview:

Thecompany to develop high performance of the large oven and heating room, can beaccurately controlled temperature. Small temperature deviation, high degree ofautomation, heating, drying and heat evenly, and accompanied by even hot airblowing drying special device. Reliable performance. The company has beensuccessfully for the Zhejiang and Tianjin Nanjing a foreign oil companiesdesign, installed heating chamber of 60-100 square meters large drying room and150 square meters. Has been used for six years without fault. High performanceof the large baking room and heating room, widely used in lubricating oil andadditives and advanced ceramic industry mold and product drying, and energy isthe best use, is a good energy-saving equipment. Nanjing Teng Yang dryingequipment factory can provide from the design, manufacture, installation andafter-sales service to the full range of quality services.

二、结构特点及工作原理

   该加热箱热空气循环系统采用立式电机水平循环送风方式，热风循环均匀高效。风源由循环送风电机带动风轮经由不锈钢电加热管，而将热风顺着侧面风道送出，再经由风道至烘箱内室，再将使用后的空气吸入顶部风道成为风源再度循环加热使用，顶部设有壹台循环风机，有足够的风力和风压来确保室内温度均匀性。当因开关保温箱的门动作引起温度值发生摆动，可介此送风循环系统迅速恢复操作状态温度值。该型号烤箱在工作温度选定后，箱内自动控制系统使温度恒温。热源采用电加热，风力强劲，运行平稳，温度自动控制，热源可采用电加热，通过温度传感器测量和计算PID自整定功能，控温精度达±1℃，进行加热、升温、恒温、温度自动控制，并有数字显示设定温度和烘箱内实际温度。该保温箱通用性强、操作简单，在工业强干扰环境下运行性能稳定，并配有超温报警灯。为了保证了执行元器件及试件的完好，整机保护系统由超温保护装置构成。

Two, structural characteristicsand working principle:

The thermal air circulationsystem of the heating box adopts the horizontal circulating air supply mode ofvertical motor, and the air circulation is uniform and efficient. Fengyuan bycyclic send wind motor drives the wind wheel via a stainless steel electricheating tube, and the hot air along the side of the air duct is sent, via airduct to an oven chamber, the use of air inhalation air duct at the top becomeair re circulation heating, with one set of circulating fan on top, enough windand air pressure to ensure that the indoor temperature uniformity. When thedoor action of the switch insulation box causes the temperature value to swing,the air circulation system can be sent to resume operation state temperaturevalue. The type of oven in the working temperature, the box automaticallycontrol system to make the temperature constant temperature. Heat source isheated by electric heating, stable operation, automatic temperature control,heat source can be used for electric heating, temperature sensor measurementand calculation of PID auto setting function, temperature control accuracy of1, heating, heating, constant temperature, automatic temperature control, and adigital display set temperature and oven temperature. The thermal insulationbox is strong, easy to operate, stable in industrial strong jamming environment,and is equipped with over temperature warning lamp. In order to guarantee theimplementation of the components and the test piece, the whole system is madeup of over temperature protective device.

The company to develop highperformance of the large oven and heating room, can be accurately controlledtemperature. Small temperature deviation, high degree of automation, heating,drying and heat evenly, and accompanied by even hot air blowing drying specialdevice. Reliable performance. The company has been successfully for theZhejiang and Tianjin Nanjing a foreign oil companies design, installed heatingchamber of 60-100 square meters large drying room and 150 square meters. Hasbeen used for six years without fault. High performance of the large bakingroom and heating room, widely used in lubricating oil and additives andadvanced ceramic industry mold and product drying, and energy is the best use,is a good energy-saving equipment. Nanjing Teng Yang drying equipment factorycan provide from the design, manufacture, installation and after-sales serviceto the full range of quality services.

三. 加热烤箱外观结构形式、耐用性：
