| 适用车型 | 中国重汽豪沃、陕汽德龙等 |
|---|---|
| 颜色 | 黑色 |
| 品牌 | 中国重汽 |
| 型号 | WG9918580002 |
| 加工定制 | 否 |
序号 SErNo | 图号 CODE | 名 称及规 格 DEscriptION & SIZE |
1 | TZ56074100006 | 轴体/Axle |
2 2a | TZ56074100007 TZ56074100008 | 左横拉杆臂/Left steering arm 右横拉杆臂/Right steering arm |
3 | TZ56074100009 | 螺栓M20X1.5X5-10.9/Screw |
4 | TZ56074100010 | 转向节臂/Steering arm |
5 | TZ56074100010 | 转向节臂/Steering arm |
6 | TZ56074100011 | 开口销5X50-Ct.O/Cotter pin |
7 | TZ56074100012 | 螺母M27X2-6H-Ct.O/Nut |
8 | TZ56074100013 | 防尘罩组合/Boot |
9 | TZ56074100014 | 衬环/Ring |
10 | TZ56074100015 | 左转向活动接头/Steering joint |
11 | TZ56074100016 | 螺栓M12X60-6h-Ct.O/Bolt |
12 | TZ56074100017 | 卡箍/Clamp |
13 | TZ56074100018 | 垫圈12-140HV/Seal ring |
14 | TZ56074100019 | 螺母M12-6h-Ct.O/Nut |
15 | TZ56074100020 | 开口销3X30Ct.O/Cotter pin |
16 | TZ56074100021 | 左转向活动接头/Steering joint0 |
17 | TZ56074100022 | 转向横拉杆总成/Steering tie rod |
18 | TZ56074100023 | 油封/Seal ring |
19 | TZ56077000139 | 圆锥滚柱轴承33122/Tapered roller bear |
20 | TZ56074100025 | 车轮紧固螺栓/Wheel mounting bolt |
21 | TZ56074100026 | 轮毂/Wheel hub |
22 | TZ56074100027 | 螺母/Nut |
23 | TZ56074100028 | 外圆锥滚柱轴承/Tapered roller bear |
24 | TZ56074100029 | 防松螺母/Nut |
25 | TZ56074100030 | 防松挡圈/Lock ring |
26 | TZ56074100031 | 垫圈8/Seal ring |
27 | TZ56074100032 | 螺栓M8X15-8.8-Ct.O/Screw |
28 | TZ56074100033 | 密封垫/Seal ring |
29 | TZ56074100034 | 端盖/Hub cap |
30 | TZ56074100034 | 垫圈8/Seal ring |
31 | TZ56074100031 | 螺栓M8X15-8.8-Ct.O/Screw |
32 | TZ56074100037 | 油杯M10X1/Grease nipple |
33 | TZ56074100038 | 上主销/King pin |
34 | TZ56074100039 | 主销衬套/Bushing |
35 | TZ56074100040 | 转向节/Steering knuckle |
36 | TZ56074100041 | 螺母20X1.5-10-Ct.O/Nut |
37 | TZ56074100042 | 限位螺钉/Screw |
38 | TZ56074100043 | 下主销/King pin |
39 | TZ56074100044 | 调整垫圈/Seal ring |
40 | TZ56074100045 | 主销阻尼轴承/Bearing |
41 | TZ56074100039 | 主销衬套/Bushing |
42 | TZ56074100047 | 45°油杯M10X1/Grease nipple |
序号 SErNo | 图号 CODE | 名 称及规 格 DEscriptION & SIZE |
1 | TZ56074100052 TZ56074100053 | 左制动凸轮轴/Left brake camshaft 右制动凸轮轴/Right brake camshaft |
2 | TZ56077000173 | 油封总成/Seal ring |
3 | TZ56074100055 | 衬套/Bushing |
4 | TZ56074100056 TZ56074100057 | 左气室支座/Left seat 右气室支座/Right seat |
5 | TZ56074100058 | 衬套/Bushing |
6 | TZ56077000176 | 油封总成/Seal ring |
7 | TZ56074100060 | 隔环/Ring |
8 | TZ56074100061 TZ56074100062 | 左调整臂/Adjuster(L) 右调整臂/Adjuster(R) |
9 | TZ56077000192 | 锁止垫圈/Stop washer |
10 | TZ56077000193 | 补偿垫圈/Compensate washer |
11 | TZ56077000194 | 垫圈/washer |
12 | TZ56077000195 | 挡圈34/Lock ring |
13 | TZ56074100067 TZ56074100068 | 左气室支座总成/Left seat assembly 右气室支座总成/Right seat assembly |
14 | TZ56077000205 | 自锁螺母/Nut |
15 | TZ56074100070 | 螺栓/Bolt |
16 | TZ56077000196 | 堵塞/Plug |
17 | TZ56077000197 | 螺栓M6X12/Bolt |
18 | TZ56077000198 | 弹簧垫圈10/Spring ring |
19 | TZ56077000199 | 螺栓M10X16 –5.6/Bolt |
20 | TZ56077000200 | 垫圈10/Washer |
21 | TZ56074100076 | 左制动托板/Brake bracket（L） |
22 | TZ56074100077 | 右制动托板/Brake bracket（R） |
23 | TZ56074100078 | 制动托架/ Brake backet |
24 | TZ56077000206 | 弹性垫圈16/Spring washer |
25 | TZ56074100080 | 螺栓M16x1.5x50-10.9/Bolt |
26 | TZ56077000208 | 制动蹄支撑销/Brake shoe supporting pin |
27 | TZ56077000209 | 衬套/Bushing |
28 | TZ56077000210 | 锁止垫圈/Stop washer |
29 | TZ56077000211 | 开口销4X50/Cotter pin |
30 | TZ56077000212 | 销轴/Shaft pin |
31 | TZ56077000213 | 滚轮/Roller |
32 | TZ56077000214 | 衬套/Bushing |
33 | TZ56077000215 | 垫圈/Washer |
34 | TZ56077000216 | 挡圈17/Shield ring |
35 | TZ56077000217 | 制动蹄回位弹簧/Spring |
36 | TZ56077000218 | 支撑销/Suporting pin |
37 | TZ56077000219 | 开口销3X35/Cotter pin |
TZ56074100100 | 制动蹄总成(C3501040D) | |
38 | TZ56074100093 | 制动蹄座/Brake shoe |
39 | TZ56074100094 | 制动摩擦片/Brake lining |
40 | TZ56074100095 | 制动摩擦片/Brake lining |
41 | TZ56077000223 | 空心铆钉/Hollow bolt |
42 | TZ56074100097 | 制动鼓 /Bake drum |
43 | TZ56074100002 | 30/30型储能弹簧制动气室（左） |
44 | TZ56074100098 | 30/30型储能弹簧制动气室(右QF-58C/4 ) |
